ALP & AL SERIES -

ALP & AL SERIES

Machine Specification

Model No.	ALP-25	ALP-32	ALP-42	AL-50	AL-60
Max. Capacity Round Bar	25 mm	32 mm	42 mm	50 mm	60 mm
Hexagonal	22 mm AF	25 mm AF	36 mm AF	42 mm AF	52 mm AF
Square	18 mm	22 mm	29 mm	36 mm	42 mm
Max. Turning Length With Long Turning Attachment	50 mm	60 mm	65 mm	70 mm	75 mm
Maximum Drill	40 mm	50 mm	60 mm	70 mm	70 mm
Spindle Speed (6)	690–2160	690–2160	440–1350	2	2
Production Rate in Pieces Per Hour	22–794	22–794	14–529	14–529	14–529
Electric Drive Motor	2 HP	3 HP	5 HP	5 HP	5 HP
3 Phase	1400 RPM	1400 RPM	900 RPM	900 RPM	900 RPM
