| Capacity | - | ATR 100 |
| Swing Over Bed | mm | 300 |
| Max Turning Dia. (Upto) | mm | 150 |
| Standard Turning Dia | mm | 100 |
| Max Turning Length | mm | 150 |
| Chuck Size | mm | 165 |
| Main Spindle | ||
| Spindle Nose | mt/min | A2-5 |
| Spindle Power | kw | 3.7/5.5 |
| Spindle Speed (inf. Variable) | RPM | 3500 |
| Feed Rates | ||
| Rapid Traverse X-Axis | mt/min | 20 |
| Rapid Traverse Z-Axis | mt/min | 20 |
| Turret/Tooling | ||
| Size (Model) | BTP | 63 |
| No. Of Tool Positions | no. | 8 |
| Tool Shank Size | mm | 20x20 |
| Max Boring Bar Dia | mm | 32 |
| CNC System | Make | Fanuc/Siemens/Delta |
| Accuracy | ||
| Positioning Accuracy | mm | ±0.003 |
| Repeatability | mm | ±0.004 |
| Parameters | ||
| Overall Size (LxBxH) | mm | 2000x1400x1650 |
| Machine Weight (Approx) | kg | 2000 |
